13" x 40" Heavy 13
®
EVS Lathe
E L E C T R I C A L
Electrical Component Location Index
Work Light
(Page 97)
Control Panel
(Page 94)
Brake Switch
(Page 97)
RPM Display & Resistor
(Page 90)
Spindle Switches
(Page 96, Behind Splash
Guard)
Oil Pressure
Sensor
(Page 96)
RPM Sensor
Coolant Pump
Motor (Page 95)
Oil Pump
Motor (Page 96)
Chuck Guard Safety Switch
(Page 97)
End gear cover
Safety Switch
(Page 97)
