Southbend South Bend SB1051 - Manual (Page 97)

For Machines Mfg. Since 5/11 13" x 40" Heavy 13 ® EVS Lathe
-95-
E L E C T R I C A L
Spindle Motor Wiring
Ground
L11 L13
W5
W2
U5
U2
V2
V5 V6
W1
U6
V1
U1
W6
W
V
U
Ground Ground
V1
U1
W1
6
4
5
3
2
1
Coolant Pump Motor Wiring
Figure 143. Coolant pump junction box.
Figure 142. Spindle motor junction box.
Junction
Box
Junction
Box
To Electrical Cabinet Terminal Board
(Page 92)
To Electrical Cabinet Terminal Board
(Page 92)
