For Machines Mfg. Since 5/11 13" x 40" Heavy 13 ® EVS Lathe
-105-
P A R T S
Gearbox Gears Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
201 PSB10510201 SPLINE SHAFT 232 PSB10510232 GEAR 19T
202 PSB10510202 OIL SEAL 20 X 32 X 5 233 PSB10510233 GEAR 20T
203 PSB10390203 NEEDLE ROLLER BEARING TAF202820 234 PSB10510234 GEAR 24T
204 PSB10510204 FLANGE BEARING 235 PSB10510235 GEAR 23T
205 PSB10510205 SPACER 236 PSB10510236 GEAR 27T
206 PR09M EXT RETAINING RING 20MM 237 PSB10510237 GEAR 24T
207 PK109M KEY 7 X 7 X 35 238 PSB10510238 GEAR 28T
208 PSB10510208 COMBO GEAR 19T/20T 239 PSB10510239 GEAR 26T
209 PSB10510209 SPLINE SHAFT 240 PSB10510240 GEAR 38T
210 PSB10510210 END COVER 241 PSB10510241 SPANNER NUT
211 P16004-OPEN BALL BEARING 16004-OPEN 242 PR10M EXT RETAINING RING 22MM
212 PSB10510212 SPACER 243 PSB10510243 COMBO GEAR 36T/50T
213 PSB10510213 COMBO GEAR 19T/30T 244 PSB10510244 GEAR 22T
214 PSB10510214 SPACER 245 PSB10510245 GEAR 22T
215 PR11M EXT RETAINING RING 25MM 246 PSB10510246 GEAR 22T
216 PSB10510216 SPLINE SHAFT 247 PSB10510247 GEAR 33T
217 PSB10510217 SPLINE SHAFT 248 PSB10510248 GEAR 22T
218 PSB10510218 WOODRUFF KEY 5 X 19 249 PR18M EXT RETAINING RING 17MM
219 PSB10510219 END COVER GASKET 250 PSB10510250 COMBO GEAR 20T/36T
220 PSB10510220 GEARBOX HOUSING 251 PSB10510251 SPACER
221 P16004-OPEN BALL BEARING 16004-OPEN 252 PSB10510252 FLANGE BEARING
222 PSB10510222 GEAR 38T 253 PSB10510202 OIL SEAL 20 X 32 X 5
223 PSB10510223 COMBO GEAR 23T/19T 254 PSB10510254 SPLINE SHAFT
224 PSB10510224 SPACER 255 PSB10510255 FLANGE BEARING
225 PR23M INT RETAINING RING 40MM 256 PSB10510256 OIL SEAL 24 X 35 X 8
226 P6203-OPEN BALL BEARING 6203 OPEN 257 PSB10510257 SHAFT
227 PSB10510227 CLUTCH 258 PK15M KEY 5 X 5 X 35
228 PSB10510228 SPACER 259 P6001-OPEN BALL BEARING 6001 OPEN
229 PR06M EXT RETAINING RING 16MM 260 PR03M EXT RETAINING RING 12MM
230 PSB10510230 GEAR 35T 261 PSB10510261 FLANGE BEARING
231 PSB10510231 GEAR 22T 324 PCAP26M CAP SCREW M6-1 X 12
