Page 115
For Machines Mfg. Since 5/11
13" x 40" Heavy 13
®
EVS Lathe
-113-
P A R T S
Saddle Top View Parts List
REF
PART #
DESCRIPTION
REF
PART #
DESCRIPTION
601
PSB10510601
GIB ADJUSTMENT SCREW
628
PSTB001
STEEL BALL 1/4"
602
PSB10510602
CROSS SLIDE
629
PSB10510629
COMPRESSION SPRING 6 X 15
603
PSB10510603
COMPOUND REST PIVOT PIN 18 X 28
630
PSB10510630
THRUST WASHER NTB/AS2 1730
604
PSB10510604
T-BOLT
631
PSB10510631
RETAINING PLATE
605
PSB10510605
CROSS SLIDE GIB
632
PSB10510632
DIAL RING
606
PSB10510606
CROSS SLIDE WAY WIPER
633
PSB10510633
CROSS SLIDE GRADUATED DIAL
607
PSB10510607
WAY WIPER PLATE
634
PSB10510634
HANDWHEEL
608
PSB10510608
THRUST WASHER NTB/AS2 1226
635
PSB10510635
HANDWHEEL END CAP
609
PSB10510609
THRUST WASHER CAP
636
PSB10510636
HANDLE
610
PSB10510610
SPACER
637
PSB10510637
HANDLE BOLT
611
PSB10510611
WEDGE KEY 7 X 7 X 30
638
PSB10510638
CARRIAGE GIB
612
PSB10510613A
LEADSCREW NUT
639
PSB10510639
REAR CARRIAGE GIB WAY
613A
PSB10510613A
LEADSCREW W/NUT ASSEMBLY
640
PSB10510640
FRONT CARRIAGE GIB WAY
613
PSB10510613A
CROSS SLIDE LEADSCREW
651
PSB10510651
ONE-SHOT OILER ASSEMBLY
614
PK168M
KEY 3 X 3 X 80
654
PK52M
KEY 3 X 3 X 15
615
PRP28M
ROLL PIN 5 X 40
655
PLUBE001
TAP-IN BALL OILER 1/4"
616
PSB10510616
COOLANT NOZZLE
656
PSS28M
SET SCREW M6-1 X 30
617
PSB10510617
COOLANT STANDING PIPE W/VALVE
657
PCAP07M
CAP SCREW M6-1 X 30
618
PSB10510618
LEADSCREW REAR BRACKET
658
PN02M
HEX NUT M10-1.5
619
PSB10510619
SADDLE
659
PW04M
FLAT WASHER 10MM
620
PSB10510620
STRAIGHT WAY WIPER
660
PS08M
PHLP HD SCR M5-.8 X 12
621
PSB10510621
STRAIGHT WAY WIPER PLATE
661
PCAP06M
CAP SCREW M6-1 X 25
622
PSB10510622
OIL CAP 3/4" NF
662
PN02M
HEX NUT M10-1.5
623
PSB10390623
TAPER PIN #6 X 2-1/2
663
PCAP02M
CAP SCREW M6-1 X 20
624
PSB10510624
V-WAY WIPER
664
PCAP35M
CAP SCREW M8-1.25 X 60
625
PSB10510625
V-WAY WIPER PLATE
666
PCAP17M
CAP SCREW M4-.7 X 10
626
PSB10510626
CROSS SLIDE PINION
667
PCAP02M
CAP SCREW M6-1 X 20
627
PSB10510627
PINION BRACKET
668
PCAP02M
CAP SCREW M6-1 X 20
