Southbend SB1014F User Manual
New & changed parts, Manual insert, Ref part # description
Manual Insert
PHONE: (360) 734-1540 •
www.southbendlathe.com
MODEL SB1014F
16" X 60" LATHE 220V w/DRO
Copyright © June, 2011 by South Bend Lathe Co.
WARNING: No portion of this manual may be reproduced without written approval.
#BL14235 Printed in USA
The Model SB1014F Lathe is the same machine as the Model SB1014 except for the following:
• Added a 2-Axis Fagor Digital Readout (DRO).
Except for the differences noted in this insert, all other content in the Model SB1014 Owner’s Manual
applies to this machine. Before operating your new lathe, you MUST read and understand this insert,
the entire Model SB1014 Owner’s Manual, and the Fagor DRO Owner’s Manual to reduce the risk of
injury when using this machine. Keep this insert for later reference.
If you have any further questions about this manual insert or the differences between the Model
SB1014F and the Model SB1014, contact our Technical Support at (360) 734-1639 or email
REF PART #
DESCRIPTION
2318 PSB1014F2318
DRO ASSEMBLY FAGOR 20i-T 2-AXIS
2407 PSB1014F2407 MACHINE ID LABEL
2416 PSB1014F2416
MODEL NUMBER LABEL
New & Changed Parts
2318
2416
2407
Made
in T
aiwan to
Sout
h Bend Specif
ication
s
MODEL SB1014F
16" x 60" EVS
TOOLR
OOM
LATHE
w/DR
O
MFG Date
Serial Nu
mber
TO REDUCE THE RISK OF SERIOUS PERSONAL INJUR
Y WHILE USING THIS
MA
CHINE:
1.
Read and understand manual bef
ore star
ting
.
2.
Always wear appro
ved e
ye protection.
3.
Make sur
e the mac
hine is c
onnec
ted to a grounded po
wer sourc
e.
4.
Keep all guards in plac
e.
5.
DO NO
T wear loose clothing
, glo
ves
, or je
welr
y; secur
e long hair and
roll up long slee
ves
.
6.
Disc
onnec
t po
wer bef
ore ser
vice, maintenanc
e, or adjustments
.
7.
DO NO
T oper
ate when tir
ed or under the influence of
drugs or alc
ohol.
8.
Make sur
e the mac
hine is proper
ly adjusted/set up bef
ore star
ting
.
9.
Change cutting fluid r
egular
ly and av
oid c
ontac
t with skin.
10.
Make sur
e w
orkpiece is proper
ly and sec
urely held in the c
huc
k and has
safe c
lear
anc
e through full rota
tion bef
ore star
ting the la
the.
11.
Nev
er leav
e the c
huc
k ke
y in the chuc
k.
12.
Nev
er touch the c
huc
k or w
orkpiece when it is in motion.
13.
Nev
er leav
e the la
the running una
ttended.
14.
Make sur
e long w
orkpiec
es ar
e proper
ly suppor
ted.
15.
Always use the proper speed r
ate f
or the ma
terial y
ou ar
e tur
ning
.
16.
Do not allo
w c
hildr
en to hav
e unsuper
vised ac
cess to the mac
hine.
WA
RNI
NG
!
!
Motor
: 7.5HP
, 220V
, 3-Ph, 60H
z
Full Load Amp D
raw: 21.7A
Swing Ov
er Bed: 16.14"
Distance Between Centers: 60"
Swing Ov
er Cros
s Slide: 10.375"
Swing Ov
er Gap: 22.95"
Spindle Nose T
o Gap (Max.): 10.2"
Cros
s Slide T
rav
el: 9"
Com
pound T
rav
el: 5.1"
Spindle Nose: D1-6 Camlock
Spindle B
ore: 2-1/16"
Taper Ins
ide Spindle
: MT#6
Taper Ins
ide T
ailstoc
k: MT#4
Weight: 3300 lbs
.
