Machine electrical overview – Southbend South Bend SB1051 User Manual
Page 89
For Machines Mfg. Since 5/11
13" x 40" Heavy 13
®
EVS Lathe
-87-
E L E C T R I C A L
Machine Electrical Overview
Work Light
(Page 97)
Spindle Motor
(Page 95)
Coolant Pump Motor
(Page 95)
Oil Pump Motor
(Page 96)
Oil Pressure Sensor
(Page 96)
Resistor (Page 90)
RPM Display (Page 90)
Electrical Cabinet
(Pages 91, 93, & 92)
Brake Switch (Page 97)
Control Panel (Page 94)
Spindle Switches (Page 96)
Chuck Guard
Safety Switch (Page 97)
Power Source
Connection (Page 97)
RPM Sensor
End gear cover
Safety Switch
(Page 97)
