Installing/mounting
5.6 Upright mounting
SIMATIC IPC427C
32
Operating Instructions, 04/2009, A5E02414743-01
5.6 Upright mounting
With the available optional vertical mounting kit you have the possibility to implement a place
saving installation.
Mounting the vertical mounting bracket onto the device
① Device ② Screws ③ Vertical mounting bracket
Note
•
Information on installation and operation is available in the supplement of the
accessories.
