4-14

Serial I/O -Configuring Term Types 18, 19, 21, 22, or 26

The printer may be attached as a spooled printer on your system. It
supports I/O status checking by responding to the interrogation string ESC
? DC1 and indicates its status concerning whether paper is loaded, printer
covers are closed, and whether or not the printer is ONLINE.

Use the printer's EXTENDED SETUP MODE to configure the following
parameters to match your host system settings:

INTERFACE

Set to SERIAL

PARITY

Set to match your host configuration as
NONE, EVEN or ODD match your host
setting

DATA LENGTH

Set to match your host configuration
(Either 7 or 8 BITS)

STOP BIT

Set to match your host configuration
(Either 1 or 2 BITS)

PROTOCOL

Set to XON/XOFF 1

BAUD RATE

Set to match your host configuration as
300,600,1200,2400,4800,9600,19200, or
38400
