96257 Sun Confidential: Internal Only B-79
Revision A
FICON Channel Extension – Sample Configurations
■
FICON Channel Extension – Sample Configurations
Figure B-1. Host-to-VTSS Channel Extension – Direct Attachment
Tape Silo
with RTDs
Channel
Extender
VTSS
A502_048
z/OS
Host
Figure B-2. Host-to-VTSS Channel Extension – Behind Single FICON Switch / Director
FICON
Director/Switch
Tape Silo
with RTDs
A502_049
z/OS
Host
VTSS
Channel
Extender
Figure B-3. Host-to-VTSS Channel Extension – Between Cascaded FICON Switches / Directors
A502_050
Tape Silo
with RTDs
Channel
Extender
VTSS
z/OS
Host
FICON
Director/Switch
FICON
Director/Switch
