96257 Sun Confidential: Internal Only A-69
Revision A
FRU Identifiers
Logic Power Supply Fans
CU Rear Tray 1 LPS0 Fan 0 FAN-0 3BD 957 CU.1.FAN0
CU Rear Tray 1 LPS0 Fan 1 FAN-1 3BE 958 CU.1.FAN1
CU Rear Tray 1 LPS1 Fan 2 FAN-2 3BF 959 CU.1.FAN2
CU Rear Tray 1 LPS1 Fan 3 FAN-3 3C0 960 CU.1.FAN3
Card Cage Impellers
CU Rear Tray 2 Card Cage Impeller 0 IMP0 38A 906 CU.2.IMP0
CU Rear Tray 2 Card Cage Impeller 1 IMP1 38B 907 CU.2.IMP1
CU Rear Tray 2 Card Cage Impeller 2 IMP2 38C 908 CU.2.IMP2
CU Rear Tray 2 Card Cage Impeller 3 IMP3 38D 909 CU.2.IMP3
Physical Array Disk Drive Tray 0
DA Rear
Physical Drive Tray 0
(Logical Tray DA0.0)
Array Drive Module 0 DRV0 8C 140 DA.0.DRV0
Array Drive Module 1 DRV1 8D 141 DA.0.DRV1
Array Drive Module 2 DRV2 8E 142 DA.0.DRV2
Array Drive Module 3 DRV3 8F 143 DA.0.DRV3
Array Drive Module 4 DRV4 90 144 DA.0.DRV4
Array Drive Module 5 DRV5 91 145 DA.0.DRV5
Array Drive Module 6 DRV6 92 146 DA.0.DRV6
Array Drive Module 7 DRV7 93 147 DA.0.DRV7
DA Rear Tray 0 Drive Tray 0 Fan FAN-0 44C 1100 DA.0.FAN
DA Front Tray 0 Tray Interface Monitor IFES 0 51 81 DA.0.IFES
Physical Array Disk Drive Tray 1
DA Rear
Physical Drive Tray 1
(Logical Tray DA0.1)
Array Drive Module 0 DRV0 96 150 DA.1.DRV0
Array Drive Module 1 DRV1 97 151 DA.1.DRV1
Array Drive Module 2 DRV2 98 152 DA.1.DRV2
Array Drive Module 3 DRV3 99 153 DA.1.DRV3
Array Drive Module 4 DRV4 9A 154 DA.1.DRV4
Array Drive Module 5 DRV5 9B 155 DA.1.DRV5
Array Drive Module 6 DRV6 9C 156 DA.1.DRV6
Array Drive Module 7 DRV7 9D 157 DA.1.DRV7
DA Rear Tray 1 Drive Tray 1 Fan FAN-1 44D 1101 DA.1.FAN
DA Front Tray 1 Tray Interface Monitor IFES 1 52 82 DA.1.IFES
Table A-4. VSM5-VTSS FRU Identifiers (Continued)
Physical
Location
FRU
Common Name
FRU
Silkscreen
FRU Number
(Hex)
FRU Number
(Decimal)
FRU Location ID
(Unit.Tray.Slot)
