Configuration Planning
2-40 Sun Confidential: Internal Only 96257
Revision A
■
Fibre Channel Cables — Available Lengths
Table 2-6. Fibre Channel Cables – Available Lengths
Description / Length Part Number
LC-LC, 9/125, Duplex, Plenum, 10 meter (32.8 ft.), RoHS-5 10800330
LC-LC, 9/125, Duplex, Riser, 10 meter (32.8 ft.), RoHS-5 10800331
LC-LC, 9/125, Duplex, Plenum, 50 meter (164 ft.), RoHS-5 10800332
LC-LC, 9/125, Duplex, Riser, 50 meter (164 ft.), RoHS-5 10800333
LC-LC, 9/125, Duplex, Plenum, 100 meter (328 ft.), RoHS-5 10800305
LC-LC, 9/125, Duplex, Riser, 100 meter (328 ft.), RoHS-5 10800306
LC-SC, 9/125, Duplex, Plenum, 10 meter (32.8 ft.), RoHS-5 10800334
LC-SC, 9/125, Duplex, Riser, 10 meter (32.8 ft.), RoHS-5 10800335
LC-SC, 9/125, Duplex, Plenum, 50 meter (164 ft.), RoHS-5 10800336
LC-SC, 9/125, Duplex, Riser, 50 meter (164 ft.), RoHS-5 10800337
LC-SC, 9/125, Duplex, Plenum, 100 meter (328 ft.), RoHS-5 10800303
LC-SC, 9/125, Duplex, Riser, 100 meter (328 ft.), RoHS-5 10800304
SC-SC, 50/125, Duplex, Plenum, 10 meter (32.8 ft.), RoHS-5 10800294
SC-SC, 50/125, Duplex, Riser, 10 meter (32.8 ft.), RoHS-5 10800297
SC-SC, 50/125, Duplex, Plenum, 50 meter (164 ft.), RoHS-5 10800295
SC-SC, 50/125, Duplex, Riser, 50 meter (164 ft.), RoHS-5 10800298
SC-SC, 50/125, Duplex, Plenum, 100 meter (328 ft.), RoHS-5 10800296
SC-SC, 50/125, Duplex, Riser, 100 meter (328 ft.), RoHS-5 10800299
Notes:
• Order plenum-rated cables for sites where cables will be routed through HVAC ductwork. Plenum cables have fire-
retardant coating to prevent release of toxic gases and smoke in case of fire, so cost more than riser cables.
• Order riser cables for sites where cables will be installed in vertical riser shafts. Riser cables cannot be used in ple-
num areas unless specifically permitted by local codes. Riser cables provided by Sun are compliant with the stan-
dard flame spread test requirements outlined in UL specification 1666.
• When ordering cables, add a ‘service loop’ of at least 4.6 m (15 ft.) of extra cable at each end of the measured
VTSS-to-host length to allow the VTSS to be moved as needed for servicing, room reconfigurations, etc. Store ex-
tra cabling either on the floor beneath the VTSS or inside the VTSS, but not in an under-floor cable trough. If in
doubt as to where locate the loop, contact the data center manager or Sun Technical Support.
