96257
Sun Confidential: Internal Only
2-33
Revision A
VTSS Configuration Planning
■
VTSS Configuration Planning
A VSM5 system consists of Virtual Tape Control System (VTCS) host software, Virtual
Tape Storage Subsystem (VTSS) disk hardware (tape buffers)
1
, real tape drives (RTDs)
which attach to an Automated Cartridge System (ACS), and automated cartridge systems
(ACSs), a.k.a. tape libraries.
A VSM5-VTSS connects to IBM S/390-equivalent data-streaming architectures and relat-
ed hardware
2
, and has front-end and back-end FICON connections. ESCON connections
are not available for VSM5-VTSS.
VSM5-VTSS Environmental Requirements
VSM5-VTSS Physical Characteristics
1. Both a primary VTSS and secondary VTSS can be used within a single system configuration.
2. Including, but not limited to: OS/390, z/OS, MVS, and VM host systems and FICON directors (switches) by Brocade, CNT, and
McData. Check with Sun product marketing for the latest certification and compatibility information for VSM systems.
Table 2-2. VSM5-VTSS Environmental Requirements
Environmental
Factor
Shipping Environment
Limits*
Storage Environment
Limits
#
Operating Environment
Limits
Temperature
-40
o
C to +60
o
C
(-40
o
F to +140
o
F)
10
o
C to 40
C
(50
o
F to 104
o
F)
16
o
C to 32
o
C
(60
o
F to 90
o
F)
Thermal Change
(maximum rate/hr)
15
C
(27
o
F)
15
o
C
(27
o
F)
5
o
C
(9
o
F)
Humidity
‡
10% to 80%
10% to 80%
20% to 80%
Altitude
0m to 15,240m
(0 ft. to 50,000 ft.)
0m to 3050m
(0 ft. to 10,000 ft.)
0m to 2439m
(0 ft. to 8000 ft.)
Notes:
• Abbreviations key: C = Centigrade; F = Fahrenheit; ft. = foot / feet; m = meter(s)
• * The shipping environment must not exceed the storage environment limits longer than 10 days.
•
#
The storage environment must not exceed the operating environment limits longer than 60 days.
•
‡
Humidity specifications exclude conditions that may cause condensation on disk drives.
Table 2-3. VSM5-VTSS Physical Characteristics
Physical Attribute
Specification
Height
154.94cm (61.0 in.)
Width (with both side covers attached)
92.1cm (36.24 in.)
Depth (with front and rear doors attached)
77.1cm (30.34 in.)
Maximum Weight (with 64 array drives)
445kg (982 lbs.)
Footprint
7093.7cm
2
(1099.5 in
2
)
Recommended Service Clearance, Front/Rear (door swing radius)
54.1cm (21.3 in.)
Recommended Left/Right Side Clearance (optional)
6.4cm (2.5 in.)
