47
1
Press the Point ◄ button to decrease the contrast; press the Point
► button to increase the contrast (from 0 to 63).
Press the Point ◄ button to decrease the brightness; press the
Point ► button to increase the brightness (from 0 to 63).
Press the Point ◄ button to lighten red tone; press the Point ►
button to deepen red tone (from 0 to 63).
Press the Point ◄ button to lighten green tone; press the Point ►
button to deepen green tone (from 0 to 63).
Press the Point ◄ button to lighten blue tone; press the Point ►
button to deepen blue tone (from 0 to 63).
Use the Point ◄► buttons to select the desired Color temp. level
(XLow, Low, Mid or High).
Press the Point ◄ button decrease the intensity of the color; press
the Point ►button increase the intensity of the color (from 0 to 63).
Press the Point ◄► buttons to adjust the tint value to get a proper
color balance (from 0 to 63).
Note:
• When White balance Red, Green or Blue is adjusted, the Color temp. level will change to Adj..
• Tint cannot be selected when the video system is PAL, SECAM, PAL-M or PAL-N (p.45).
Image adjust Menu
Contrast 32
Brightness 32
Color 32
Tint 32
Color temp. High
Red 28
Green 32
Blue 35
Offset
Sharpness 8
Gamma 8
Reset
Store
1/2
Selected Image mode
Press the MENU button to display the On-Screen Menu. Use
the Point ▲▼ buttons to select Image adjust and then press
the Point ► or the SELECT button.
Use the Point ▲▼ buttons select the desired item and then
press the SELECT button to display the adjustment dialog
box. Use the Point ◄► buttons to adjust the setting value.
Use the Point ◄►
buttons to adjust the
setting value.
Video Input
Image Adjustment
Contrast
Brightness
Color
Tint
Color temp .
White balance (Green)
White balance (Red)
White balance (Blue)
