41
Computer Input
Image adjust Menu Press the MENU button to display the On-Screen Menu.
Use the Point
▲▼ buttons to select Image adjust and
then press the Point ► or the SELECT button.
1
Use the Point ▲▼ buttons to select the desired item
and then press the SELECT button to display the
adjustment dialog box. Use the Point
◄► buttons to
adjust the setting value.

Note:
When White balance Red, Green or Blue is
adjusted, Color temp. will change to Adj..
Press the Point ◄ button to decrease the contrast; press the Point
► button to increase the contrast (from 0 to 63).
Press the Point ◄ button to decrease the brightness; press the
Point ► button to increase the brightness (from 0 to 63).
Press the Point ◄ button to lighten red tone; press the Point ►
button to deepen red tone (from 0 to 63).
Press the Point ◄ button to lighten green tone; press the Point ►
button to deepen green tone (from 0 to 63).
Press the Point ◄ button to lighten blue tone; press the Point ►
button to deepen blue tone (from 0 to 63).
Use the Point ◄► buttons to select the desired Color temp. level
(XLow, Low, Mid or High).
Use the Point ◄► buttons to adjust the gamma value to obtain a
better balance of contrast (from 0 to 15).
Press the Point ◄ button to decrease the sharpness of the image;
press the Point ► button to increase the sharpness of the image
(from 0 to 31).
Contrast 32
Brightness 32
Color temp. High
Red 28
Green 32
Blue 35
Offset
Sharpness 8
Gamma 8
Reset
Store
Use the Point ◄►
buttons to adjust the
setting value.
Selected Image mode
Press the Point ◄ button to lighten red/green/blue tone of the black
level of an image; press the Point ► button to deepen red/green/
blue tone of the black level of an image.
Image Adjustment
Contrast
Brightness
Color temp .
White balance (Red)
White balance (Green)
White balance (Blue)
Offset(Red/Green/Blue)
Sharpness
Gamma
