CV503-8CH-19M

SVAT ELECTRONICS

now you can see

SPECIFICATIONS

Camera Type ..........................................................................................Weather resistant Color IR CCD

Camera

Image Sensor ........................................................................................1/4" Color SHARP CCD

Resolution ............................................................................................420 TV Lines

Outdoor Use ..........................................................................................Yes

IP Rating ...............................................................................................IP65

Focal Length ..........................................................................................3.6mm

Focus Type .............................................................................................Fixed

Optimal Focal Distance ...........................................................................20 ft

Motion detection ...................................................................................No

Night Vision ..........................................................................................Yes

Number of IR LEDs and Range .................................................................12, up to 15ft

IR LED Control ........................................................................................Automatic (CDS Sensor)

Min. Illumination ...................................................................................0 lux

IR Wavelength .......................................................................................850nm

Video Output .........................................................................................4 PIN DIN to RCA

TV System .............................................................................................NTSC

Viewing Angle .......................................................................................60 Degrees

Electronic Shutter ..................................................................................1/60 ~ 1/100000 sec

BLC .......................................................................................................No

AGC .......................................................................................................Automatic

ELC ........................................................................................................Automatic

Line Lock ...............................................................................................No

Iris Control ............................................................................................No

Gamma Correction .................................................................................>0.45

White Balance .......................................................................................Automatic

Sun Shield .............................................................................................Yes

IR Cut Filter ...........................................................................................No

Housing Material ...................................................................................Anodized Aluminum

Housing Color ........................................................................................Silver

Signal/Noise Ratio .................................................................................>48dB

Camera Bracket .....................................................................................Yes

Lens Mount type ....................................................................................M12

Pan/Tilt/Zoom .......................................................................................No

Operating Temperature ..........................................................................-10° ~ 60°C / Degrees

Operating Humidity ...............................................................................98%

Camera Power Input ..............................................................................DC 12V 300mA

Power Adapter Input ..............................................................................120V 60Hz

LED Power Indicator ...............................................................................No

Dimensions ...........................................................................................4.7”(L) x 2.5”(W) x 2.5”(H)

Weight ..................................................................................................0.7 lbs
