MAIN MENU
Position
This will determine where the title of the camera will be displayed. Selecting “OFF” will provide no title on screen for
desired camera.
To Change the Position of your Camera’s Name:
1. Under the “POSITION” column, navigate to and select the drop down list of the channel’s name you would like to
reposition.
2. Select which quadrant of the screen you want that camera’s title to appear.
3. Repeat for all desired cameras.
4. Select “APPLY” to save changes.
Color
Selecting this prompts four adjustable values
for each camera: hue, brightness, contrast and
saturation.
To Adjust Coloring:
1. After selecting the color option in the
“CAMERA SETUP,” navigate to a color
setting you would like to adjust.
2. When the desired color setting is
highlighted, left click to a location on the
line to adjust the settings accordingly.
3. When desired changes have been made,
select “APPLY” to save your changes.
Live
This option allows you to turn a camera on or off in live viewing mode. When selected off, the camera will still record
but it will not be displayed on screen. This is useful if you have a camera placed in a confidential area or if you have a
camera location you wish to remain hidden.
To turn the live viewing of a camera on or off:
1. Navigate to and select the “LIVE” drop down list next to the camera you would like to turn on/off.
2. Select “OFF” to prevent live camera display or “ON” to remain live.
3. Repeat for all desired cameras.
4. Select “APPLY” to save your changes.
Color Setup
