WHAT IS INCLUDED
FEATURES
4 x Indoor/Outdoor
Night Vision CCD Color
Cameras
4 PIN DIN to RCA (male)
Video/Power Wire
• BNC to RCA Connector
• 1 Power Adapter for Cameras
• Mounting Hardware
• Instruction Manual
• 1 Year Warranty
• Online/Toll Free Support
VU301-C Camera
1. Sun Shield: Helps prevent glare from bright
lights
2. Infrared (IR): LEDs allow the camera to see in
the dark up to 15ft away.
3. CDS Sensor: Automatically turns on the
infrared LEDs when it gets dark
4. Camera Housing: Made of anodized aluminum to
prevent rust
5. Camera Mount: Allows the camera to be desk or
wall mountable
6. 4 PIN DIN Female Connection (connects to
male RCA)
One to Four Power Supply Cable
1. Female 12V Connection
2. Camera Power Supply Ports
The One to Four power Supply Cable allows you to plug
four cameras into one power source, saving you time
and space.
IMPORTANT INFORMATION
While this camera is weather resistant, it is not
waterproof. Please do not install it in areas that receive
direct rain or under eaves trough draining spots. Do not
cut the DC power cable of this camera to fit with another
power source. Do not cut the video connection wire to fit
with a different video connection type. Any unauthorized
modifications will void your warranty.
