-5-
N(/()Fne\ijDXelXcD]^%j`eZ\*&'0
@EKI
F;L:
K@FE DX`eJg\Z`]`ZXk`fej
:lkk`e^:XgXZ`k`\j
Maximum Planing Width ............................................................................................... 7"
Maximum Planing Depth .............................................................................................
1 ⁄
8
"
Maximum Planing Height ........................................................................................... 7 1 ⁄
2
"
Maximum Profile Width ............................................................................................ 6 3 ⁄
4
"
Maximum Profile Depth .............................................................................................. 3 ⁄
4
"
Minimum Stock Thickness ............................................................................................ 1 ⁄
4
"
Minimum Stock Length ................................................................................................ 9"
Be`]\@e]fidXk`fe
Number of Knives ....................................................................................................... 2
Knife Type ............................................................................................................. HSS
Knife Length ......................................................................................................... 7
1 ⁄
8
"
Knife Width ........................................................................................................... 1 1 ⁄
2
"
Knife Thickness ........................................................................................................ 1 ⁄
4
"
Number of Cuts Per Minute ......................................................................................14,000
Number of Cuts Per Inch .........................................................................................64-300
:lkk\i_\X[@e]fidXk`fe
Cutterhead Type .................................................................................................. Square
Cutterhead Diameter ............................................................................................... 1
1 ⁄
4
"
Cutterhead Speed ............................................................................................. 7000 RPM
KXYc\@e]fidXk`fe
Table Length w/Wings ............................................................................................. 36 1 ⁄
4
"
Table Length w/o Wings........................................................................................... 14 1 ⁄
8
"
Table Width ............................................................................................................ 10"
Table Thickness .......................................................................................................
7 ⁄
16
"
Extension Wing Length ............................................................................................... 11"
Extension Wing Width ..............................................................................................8
9 ⁄
16
"
Floor to Table Height .............................................................................................. 30 3 ⁄
8
"
Fk_\i@e]fidXk`fe
Number of Dust Ports ................................................................................................... 1
Dust Port Size ........................................................................................................... 4"
Measurement Scale Units ........................................................................................ Inches
:fejkilZk`feDXk\i`Xcj
Cabinet ........................................................................................................... Formed Steel
Body Assembly ......................................................................................................... Cast Iron
Cutterhead Assembly ......................................................................................................Steel
Table & Extension Wing ........................................................................ Precision Ground Cast Iron
Paint ............................................................................................................... Powder Coat
Infeed and Outfeed Rollers ...........................................................................Rubber Coated Steel
Fk_\i
Serial Number Location ........................................................................ ID Label on Front of Stand
Customer Assembly Time ....................................................................... Approximately 45 Minutes
Warranty .................................................................................................................. 2 Year
Country of Origin ....................................................................................................... Taiwan
=\Xkli\j
Heavy-Duty Cast Iron Handwheel with Inch Measurement Scale for Cutterhead Housing Lift
Precision-Ground Cast Iron Infeed and Outfeed Extension Wings
Dovetailed Way for Cutterhead Housing with Precision Gib Adjustments
Pedestal-Mounted Control Switch with Variable Speed Control
