Dfkfixe[:fekifcjgxikjc`jk, G8 i k j – Woodstock W1812 User Manual
Page 52
-49-
N(/()Fne\ijDXelXcD]^%j`eZ\*&'0
G8
I
K
J
=\\[DfkfiXe[:fekifcjGXikjC`jk
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
301
X1812301
FEED ROLL SPROCKET
352 X1812352
CHAIN COVER
302
X1812302
FEED MOTOR 1/4 HP 220V
353 X1812353
INFEED ROLLER DRIVE CHAIN
302-1 X1812302-1
FEED MOTOR POWER CORD
354 X1812354
OUTFEED ROLLER DRIVE CHAIN
302-2 X1812302-2
FEED MOTOR BRUSH SET
355 XP6902-2RS
BALL BEARING 6902-2RS
302-3 X1812302-3
PLASTIC LOCK SCREW
356 XPLW01M
LOCK WASHER 5MM
302-4 X1812302-4
DRIVE GEAR
358 XP608-2RS
BALL BEARING 608-2RS
303
X1812303
STEEL CONDUIT
366 X1812366
CHAIN TENSIONER FOOT
304
X1812304
PLASTIC CONDUIT
367 XPN02
HEX NUT 5/16-18
305
X1812305
STAND
368 X1812368
CONSOLE UNIT POWER CORD
306
XPS06
PHLP HD SCR 10-24 X 3/8
374 X1812374
CONTROL BOX
307
XPFH05
FLAT HD SCR 1/4-20 X 3/4
375 X1812375
CONTROL BOX BRACKET
309
X1812309
GROMMET 30MM
376 X1812376
CONTROL PLATE
310
XPB07
HEX BOLT 5/16-18 X 3/4
377 X1812377
ON SWITCH
310-1 XPB03
HEX BOLT 5/16-18 X 1
378 X1812378
OFF SWITCH
311
XPW07
FLAT WASHER 5/16
379 X1812379
CONTROL CORD
312
XPN02
HEX NUT 5/16-18
380 XPS19M
PHLP HD SCR M5-.8 X 6
315
X1812315
MACHINE POWER CORD 220V
381 X1812381
END CAP
315-1 X1812315-1
CUTTERHEAD MOTOR POWER CORD
382 X1812382
BRUSH HOUSING
315-2 X1812315-2
CONTROL PANEL POWER CORD
383 X1812383
THERMOCOUPLE
319
X1812319
VARIABLE SPEED CONTROL KNOB
384 X1812384
STATOR HOUSING
321
X1812321
BOTTOM COLOR STRIPE
385 XPTLW08M
EXT TOOTH WASHER 10MM
322
X1812322
UPPER COLOR STRIPE
386 XP6200-2RS
BALL BEARING 6200-2RS
323
XPHTEK36
TAP SCREW #6 X 3/8
387 X1812387
ARMATURE
325
XPB19
HEX BOLT 1/4-20 X 1/2
388 XPR06M
EXT RETAINING RING 16MM
326
X1812326
PULLEY COVER
389 XP6203-2RS
BALL BEARING 6203-2RS
327
XPS06
PHLP HD SCR 10-24 X 3/8
390 XP6202-2RS
BALL BEARING 6202-2RS
328
X1812328
CABLE CLAMPS
391 X1812391
SHIM
333
X1812333
MOTOR CASE SCREW M5-.8 X 133
392 XPK34M
KEY 5 X 5 X 20
334
XPSS29
SET SCREW 10-24 X 1/4
393 X1812393
SPACER
338
XPW04M
FLAT WASHER 10MM
394 XPLW01M
LOCK WASHER 5MM
339
XPN07
HEX NUT 10-24
395 XPS20M
PHLP HD SCR M5-.8 X 15
340
X1812340
SPEED CONTROL SWITCH
396 X1812396
COVER
342
X1812342
CONSOLE UNIT
397 X1812397
CASE
342-1 XPHTEK28M
TAP SCREW M4 X 25
398 X1812398
GEAR SHAFT
350
XPW06
FLAT WASHER 1/4
399 XPRP44M
ROLL PIN 3 X 10
351
XPSB159M
CAP SCREW 1/4-20 X 2
