-4-
N(/()Fne\ijDXelXcD]^%j`eZ\*&'0
@EKI
F;L:
K@FE
DXZ_`e\Jg\Z`]`ZXk`fej
Phone #: (360) 734-3482 • Online Tech Support: [email protected] • Web: www.shopfox.biz
B68=>C:
HE:8>;>86I>DCH
Fm\iXcc;`d\ej`fej
Weight .................................................................................................................. 306 lbs.
Length ...................................................................................................................... 36
1 ⁄
4
"
Width .......................................................................................................................... 22"
Height ...................................................................................................................... 34
1 ⁄
2
"
Foot Print (Length x Width) ......................................................................................... 21" x 19"
J_`gg`e^;`d\ej`fej
Total Shipping Weight ................................................................................................. 324 lbs.
Box 1 Length x Width x Height ..................................................................... 40
1 ⁄
8
" x 19 3 ⁄
4
" x 22 1 ⁄
8
"
Box 1 Weight ........................................................................................................... 185 lbs.
Box 2 Length x Width x Height ..................................................................... 22
7 ⁄
8
" x 21 1 ⁄
4
" x 30 1 ⁄
4
"
Box 2 Weight ........................................................................................................... 139 lbs.
Switch ................................................................. Magnetic Switch w/Thermal Overload Protection
Switch Voltage ............................................................................................................. 220V
Cord Length ................................................................................................................ 10 ft.
Cord Gauge ............................................................................................................ 14 gauge
Recommended Breaker Size ...........................................................................................15 amp
Plug .............................................................................................................................No
Dfkfij
:lkk\i_\X[
Type ................................................................................... TEFC Capacitor Start Induction
Horsepower .......................................................................................................... 2 HP
Voltage ................................................................................................................ 220V
Phase ................................................................................................................ Single
Amps ................................................................................................................... 12A
Speed ............................................................................................................ 3450 RPM
Cycle ................................................................................................................. 60 Hz
Number Of Speeds ...................................................................................................... 1
Power Transfer ...................................................................................... Power Twist V-Belt
Bearings ....................................................................................... Shielded and Lubricated
=\\[Ifcc\ij
Type ......................................................................................................... DC Universal
Horsepower ........................................................................................................
1 ⁄
4
HP
Voltage, Amps ............................................................................................. 180VDC, 1.5A
Phase ................................................................................................................ Single
Motor Speed ....................................................................... 0-55 RPM (w/(Voltage Reduction)
Feed Speed ......................................................................................................0-18 FPM
Cycle ................................................................................................................. 60 Hz
Number Of Speeds ......................................................................................Variable Speed
Power Transfer ...............................................................................................Chain Drive
BD9:AL&-&'H=DE;DM
K6G>67A:HE::9EA6C:G$BDJA9:GL>I=HI6C9
