Woodstock W1812 - Manual (Page 49)

-46-
N(/()Fne\ijDXelXcD]^%j`eZ\*&'0
G8
I
K
J
?\X[jkfZbGXikjC`jk
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 XPS07M PHLP HD SCR M4-.7 X 8 39 X1812039 SWING ARM AXIS SCREW
2 XPN06 HEX NUT 1/2-12 40 X1812040 DRIVEN AXLE
3 XPN05 HEX NUT 1/4-20 41 X1812041 HEAD CASTING
4 XPB25 HEX BOLT 3/8-16 X 1-3/4 42 X1812042 SWING ARM STOP PIN
5 X1812005 KNOB 43 X1812043 ROLLER PRESSURE SCREW
6 X1812006 HANDWHEEL 44 X1812044 COMPRESSION SPRING
7 XPN08 HEX NUT 3/8-16 45 X1812045 ROLLER PRESSURE PIN
8 XPSS11 SET SCREW 1/4-20 X 1/4 46 X1812046 INFEED DRIVE AXLE
9 XPN08 HEX NUT 3/8-16 47 X1812047 INFEED SWING ARM
10 XPSS08 SET SCREW 5/16-18 X 1/2 56 X1812056 KNOB 1/4-20
11 X1812011 TOP BRACE 57 X1812057 CHIP DEFLECTOR AXIS PIN
12 XPW14 FLAT WASHER 5/8 59 XPCAP03 CAP SCREW 5/16-18 X 1
13 XP51104 THRUST BEARING 51104 60 X1812060 BALL PLUNGER 3/8-16 X 3/4
14 XPRP73M ROLL PIN 4 X 30 61 X1812061 ECCENTRIC BUSHING
15 XPSS01 SET SCREW 5/16-18 X 1 62 XPFH12 FLAT HD SCR 1/4-20 X 1
16 X1812016 DOVETAILED COLUMN 63 XPS07 PHLP HD SCR 1/4-20 X 3/8
17 X1812017 SCALE 64 X1812064 POINTER
18 X1812018 SCALE COLLAR 65 X1812065 GIB
19 X1812019 ELEVATING SCREW 68 X1812068 SCALE ROLLER SCREW
20 XPSS02 SET SCREW 5/16-18 X 3/8 69 X1812069 PLANER KNIFE SET
21 X1812021 CUTTERHEAD PULLEY 70 XPW02 FLAT WASHER 3/8
22 X1812022 ROTATION LABEL 71 XPB18 HEX BOLT 3/8-16 X 1
23 X1812023 COLLAR 72 X1812072 INNER RAIL
24 X1812024 SPACER 73 X1812073 OUTER RAIL
25 X1812025 BALL BEARING 6206 2RS+NR 80 X1812080 WINDOW
26 X1812026 CUTTERHEAD 81 X1812081 EXTENSION WING
27 X1812027 TABLE 82 XPB24 HEX BOLT 3/8-16 X 1-1/4
28 X1812028 LOCK LEVER ASSEMBLY 83 X1812083 T-NUT M6-1
29 XPCAP06 CAP SCREW 1/4-20 X 1 84 X1812084 LEVER ASSEMBLY M6-1
30 X1812030 DUST COVER 90 X1812090 POINTER
31 X1812031 CHIP DEFLECTOR 91 XPN02 HEX NUT 5/16-18
32 XPB18 HEX BOLT 3/8-16 X 1 92 XPFB05 FLANGE BOLT 10-24 X 1/2
33 X1812033 FEED ROLL SPROCKET 93 XPW07 FLAT WASHER 5/16
34 XPSS29 SET SCREW 10-24 X 1/4 95 X1812095 COLLAR
35 X1812035 OUTFEED DRIVE AXLE 96 XPFB17 FLANGE BOLT 10-24 X 3/8
36 X1812036 NEEDLE BEARING 97 X1812097 SCALE HUB
37 X1812037 RUBBER FEED ROLLER 98 XPS06 PHLP HD SCR 10-24 X 3/8
38 X1812038 OUTFEED SWING ARM 99 XPLW04 LOCK WASHER 3/8
