-29-
N(/()Fne\ijDXelXcD]^%j`eZ\*&'0
FG
<
I
8
K@FEJ
Figure 41. Correct workpiece support.
INCORRECT
CORRECT
<[^\Dflc[`e^KXccNfibg`\Z\j
When cutting edge profiles on workpieces that are taller
than they are wide, you must clamp wooden extension
rails to the table so they support at least 75% of the
workpiece height on both sides (Figure 41).
Never attempt to use the low profile metal guide rails
that came with this machine if they do not adequately
support the workpiece, such as with tall workpieces. If
the workpiece slips out of rails because the rails are too
low, the workpiece can be ejected from the machine
causing severe injury.
