-15-
N(/()Fne\ijDXelXcD]^%j`eZ\*&'0
J<
K
L
G
=`^li\13.Switch pedestal installation.
((. Feed the switch pedestal wiring harnesses into the
cabinet through the hole in the cabinet and secure
the switch pedestal to the cabinet ( =`^li\13)with
three 5 ⁄
16
"-18 x 3 ⁄
4
" hex bolts and 5 ⁄
16
" flat washers.
(). Plug the harnesses into their respective sockets just
below the pedestal mounting.
(*. Insert the feed motor wiring harness through the
conduit and loom clamps, and then plug it into the
motor.
(+. Fasten the conduit mounting bracket (=`^li\14) to
the headstock with two 5 ⁄
16
"-18 x 3 ⁄
8
" flange screws.
(,. Install two T-nuts in each table slot (=`^li\15).
(-. Position the inner and outer guide rails so the
elongated T-nut slots ( =`^li\15)are positioned on
the infeed table.
(.. Insert the lock levers through the guide rails, and
then thread them into the T-nuts.
(/. Snug the levers in place.
=`^li\14.Conduit installation.
=`^li\15.Rail installation.
Inner
and
outer
Rails
Slot
Wiring
Harness
and
Loom
Clamps
Conduit
Mounting
Bracket
Switch
Pedestal
Mounting
Bracket
