ERX 8.0.x Hardware Guide
Figure 33: I/O Module with SC Full Duplex Connectors
Port 0
Port 1
TX
RX
TX
RX
OC3
I/O
g013759
SMB Connectors
To cable I/O modules with SMB connectors, pull back the metal sheath on the
connector, insert the connector into the selected port, and release the metal sheath.
70
Cabling I/O Modules
