Cabling I/O Modules
This section illustrates the common connector types used with ERX
I/O modules. For information about the connectors on the different
line modules, see the ERX Module Guide.
BNC Connectors
Figure 29: I/O Module with BNCs
CT3
I/O
Port 0
Port 1
TX
RX
RX
TX
g013755
HSSI Connectors
The HSSI I/O module uses a standard 50-pin HSSI connector.
CAUTION:
Do not terminate HSSI connections with SCSI connectors. Although
SCSI connectors look very similar to HSSI connectors, using SCSI connectors on
HSSI connections can lead to data loss.
