Cabling ERX Routers
Required Tools, Wires, and Cables
Cabling your system takes only a few minutes. You need the following
items and those listed in Table 7 for proper installation:
1/8–inch flathead screwdriver
3/8–inch wrench or 3/8–inch nut-driver
No. 2 Phillips screwdriver
Ground wires—We recommend a minimum of 10-AWG ground wire.
#10 (ERX-7xx and ERX-14xx models) or #8 (ERX-310 router) kep nut to
connect the ground (earth) wire to the ground terminal.
Power input module wiring—We recommend a minimum of 8-AWG wire for
ERX-14xx models, 12-AWG wire for ERX-7xx models, and 14-AWG wire for
ERX-310 routers (DC model) with a dual stud terminal lug with 5/8–inch
spacing. For the ERX-310 router AC model, use a standard IEC power cord.
Consider the distance from the connection point and the configuration of the
system when determining the size of wire used.
See “System Specifications” on page 119 for more information on router
specifications.
Table 7: Required Cables
Connection Port and Cable Used
Management connection between SRP I/O module and the
LAN One 10/100Base-T Ethernet management port with an RJ-45
connector
Management connection between SRP I/O module and a
management console One RS-232 port with a DB-9 connector for VT100
management access
Direct connections to I/O modules See the ERX Module Guide for specific I/O module connector
information
NOTE: If you plan to use a cable-management bracket (ERX-7xx and ERX-14xx
models only), install it before you begin cabling your router. Cable-management
brackets are helpful to keep network interface cables untangled and orderly
and to prevent cables from hindering access to other slots. See “Installing a
Cable-Management Bracket on ERX-7xx Models” on page 100.
Required Tools, Wires, and Cables 55
