ERX 8.0.x Hardware Guide
Pin
Signal
Pin
Signal
14
Port 16 TX TIP
39
Port 16 TX RING
15
Port 17 RX TIP
40
Port 17 RX RING
16
Port 17 TX TIP
41
Port 17 TX RING
17
Port 18 RX TIP
42
Port 18 RX RING
18
Port 18 TX TIP
43
Port 18 TX RING
19
Port 19 RX TIP
44
Port 19 RX RING
20
Port 19 TX TIP
45
Port 19 TX RING
21
no connect
46
no connect
22
no connect
47
no connect
23
no connect
48
no connect
24
no connect
49
no connect
25
no connect
50
no connect
150
CT1 and CE1 I/O Modules
