Flexible Frame Relay
•
Frame Relay
•
Frame Relay for CCC
•
Frame Relay for TCC
•
Frame Relay port CCC
•
High-Level Data Link Control (HDLC)
•
HDLC framing for CCC
•
HDLC framing for TCC
•
MPLS CCC
•
MPLS TCC
•
Multilink Frame Relay (MLFR) UNI NNI (MFR FRF.16)
•
Point-to-Point Protocol (PPP)
•
PPP for CCC
•
PPP for TCC
•
Standard DS3 BNC coaxial cable interfaces
Cables and connectors
One tricolor per port:
•
Off—Not enabled
•
Green—Online with no alarms or failures
•
Yellow—Online with alarms for remote failures
•
Red—Active with a local alarm; router has detected a failure
LEDs
•
DS3 alarms:
•
Alarm indication signal (AIS)
•
Loss of frame (LOF)
•
Loss of signal (LOS)
•
Phase lock loop (PLL)
•
Yellow alarm
•
DS3 error detection:
•
C-bit code violations (CCV)
•
C-bit errored seconds (CES)
•
C-bit severely errored framing seconds (CEFS)
•
CRC errors
•
Excessive zeros (EXZ)
•
Far-end block error (FEBE)
•
Far-end receive failure (FERF)
•
Line errored seconds (LES)
•
Parity bit (P-bit) code violations (PCV)
•
Parity bit (P-bit) errored seconds (PES)
•
Parity bit (P-bit) severely errored framing seconds (PSES)
•
Severely errored framing seconds (SEFS)
•
Unavailable seconds (UAS)
Alarms, errors, and
events
•
Layer 2 per-queue and per-channel packet and byte counters
Instrumentation
(counters)
