M7i PICs Supported
Table 1 on page 4 lists the PICs supported by the M7i router. The PICs are listed
alphabetically by PIC family.
Table 1: PICs Supported in the M7i Router
First Junos OS
Release
Support
Connector Model Number Ports PIC Family and Type
ATM2 IQ
6.1 Coaxial:
• 10 ft (3.05 m)
posilock SMB
to BNC
(provided)
• Four pairs of
Rx and Tx
coaxial cables
PE-4DS3-ATM2 4 “ATM2 DS3 IQ PIC (M7i Router)” on
page 16
6.1 Coaxial:
• 10 ft (3.05 m)
posilock SMB
to BNC cable
(provided)
• Four pairs of
Rx and Tx
coaxial cables
PE-2E3-ATM2 2 “ATM2 E3 IQ PIC (M7i Router)” on
page 18
6.0 • Optical: SC/PC PE-2OC3-ATM2-MM
PE-2OC3-ATM2-SMIR
2 “ATM2 OC3/STM1 IQ PIC (M7i
Router)” on page 20
6.0 • Optical: SC/PC PE-1OC12-ATM2-MM
PE-1OC12-ATM2-SMIR
1 “ATM2 OC12/STM4 IQ PIC (M7i
Router)” on page 22
Channelized IQ
6.0 Coaxial
• Standard DS3
BNC coaxial
cable
interfaces
PE-4CHDS3-QPP 4 “Channelized DS3 IQ PIC (M7i
Router)” on page 24
9.1R4
9.2R3
9.3R1 • 120-ohm
RJ-48C PE-10CHE1-RJ48-QPP-N 10 “Channelized E1 IQ PIC (M7i
Router)” on page 29
7.1 • Optical: SC/PC PE-1CHOC3-SMIR-QPP 1 “Channelized OC3 IQ PIC (M7i
Router)” on page 34
