Channelized OC3/STM1 Enhanced IQ (IQE) with SFP (M7i Router)
S T A TUS
PORT 1
PORT 0
TX
TX
RX
RX
g006019
• Junos OS Release 10.2 and later Software release
• Two OC3 or STM1 ports
• SONET or SDH is configurable on a per-port granularity
• SONET channelization:
• 2 OC3 channels
• 6 DS3 channels
• 168 DS1 channels
• 1011 DS0 channels
• SDH channelization:
• 2 STM1 channels (non-concatenated)
• 6 E3 channels
• 126 E1 channels
• 6 DS3 channels
• 168 DS1 channels
• 1011 DS0 channels
• Power requirement: 0.56 A @ 48 V (27.1 W)
Description
• Ports are numbered 0 and 1 from left to right Hardware features
39 Copyright © 2010, Juniper Networks, Inc.
Channelized OC3/STM1 Enhanced IQ (IQE) with SFP (M7i Router)
