• Duplex LC/PC connector (Rx and Tx); single-mode fiber
• SONET/SDH OC12/STM4 fiber-optic SFP transceivers:
• Short reach (model number: SFP-OC12-SR)
• Intermediate reach (IR-1) (model number: SFP-OC312-IR)
• Long reach (LR-1) (model number: SFP-OC12-LR)
Optical interface specifications—see SONET/SDH OC12/STM4 Optical Interface Specifications
Cables and connectors
One tricolor per port:
• Off—Not enabled
• Green—Online with no alarms or failures
• Yellow—Online with alarms for remote failures
• Red—Active with a local alarm; router has detected a failure
LEDs
Alarms, errors, and
events • SONET alarms:
• Alarm indication signal—line (AIS-L)
• Alarm indication signal—path (AIS-P)
• Bit error rate—signal degrade (BERR-SD)
• Bit error rate—signal fail (BERR-SF)
• Loss of frame (LOF)
• Loss of light (LOL)
• Loss of pointer (LOP)
• Loss of signal (LOS)
• Payload label mismatch (PLM-P)
• Remote defect indication—line (RDI-L)
• Remote defect indication—path (RDI-P)
• Remote error indication (REI)
• Payload unequipped (unequipped STS at path level) (UNEQ-P)
• Virtual container—alarm indication signal (VAIS)
• Virtual container—loss of pointer (VLOP)
• Virtual container—mismatch (VMIS)
• Virtual container—remote defect indication (VRD1)
• Virtual container—unequipped (VUNEQ)
• SDH alarms:
• Administrative unit alarm indication signal (AU-AIS)
• Bit error rate—signal degrade (BERR-SD)
• Bit error rate—signal fail (BERR-SF)
• Bit interleaved parity (BIP) error B1, B2, B3
• Higher order path—alarm indication signal (HP-AIS)
• Higher order path—far-end receive failure (HP-FERF)
• Higher order path—payload label mismatch (HP-PLM)
• Higher order path—loss of pointer (HP-LOP)
• Higher order path—remote defect indication (HP-RDI)
• Higher order path—unequipped (HP-UNEQ)
• Loss of frame (LOF)
• Loss of light (LOL)
• Loss of signal (LOS)
