Multiservices 100 PIC (M7i Router)
• Junos OS Release 8.1 and later Software release
• Supports tunnel services. This feature is included with the PIC and does not require an individual
license.
• Individual licenses must be purchased for additional services.
• Power requirement: 0.52 A @ 48 V (25 W)
Description
• Active monitoring on up to 1.6 million flows Hardware features
• Support for up to 2000 service sets
• Support for MTUs up to 9192 bytes for Gigabit Ethernet and SONET interfaces
Depending on your Junos OS Release and individual licenses, software features for this PIC can
include the features listed in Table 3 on page 84. For more information about the software features
available for services PICs, see the Junos OS Services Interfaces Configuration Guide.
Software features
Status LED, one tricolor:
• Off—PIC is offline and it is safe to remove it from the chassis.
• Green—PIC is operating normally.
• Yellow—PIC is initializing.
• Red—PIC has an error or failure and no further harm can be done by removing it from the chassis.
Application LED, one bicolor:
• Off—Service is not running.
• Green—Service is running under acceptable load.
• Yellow—Service is overloaded.
LEDs
Table 3: Multiservices PICs Software Features Supported by the M7i Router
Multiservices 100 Software Feature
8.1 GRE Key
8.1 GRE dont-fragment
8.1 Stateful firewall with packet inspection: detects SYN attacks, ICMP and UDP floods, and
ping of death attacks
Copyright © 2010, Juniper Networks, Inc. 84
M7i Multiservice Edge Router PIC Guide
