OK LED, one tricolor:
•
Off—PIC is offline and it is safe to remove it from the router.
•
Green—PIC is operating normally.
•
Yellow—PIC is initializing.
•
Red—PIC has an error or failure.
APP LED, one bicolor:
•
Off—Monitoring application is not running.
•
Green—Monitoring application is running under acceptable load.
One tricolor per port:
•
Off—Not enabled
•
Green—Online with no alarms or failures
•
Yellow—Online with alarms for remote failures
•
Red—Active with a local alarm; router has detected a failure
LEDs
Structure agnostic alarms for T1 interface:
•
Alarm indication signal (AIS-L, AIS-P)
•
Loss of signal (LOS)
•
Errored seconds (ES)
•
Line-errored seconds (LES)
•
Severely errored seconds (SES)
•
Unavailable errored seconds (UAS)
•
Bipolar violation (BPV)
•
Controlled slip (CS)
•
Line code violation (LCV)
Structure agnostic alarms for E1 interface:
•
Alarm indication signal (AIS-L, AIS-P)
•
Loss of signal (LOS)
•
Errored seconds (ES)
•
Line-errored seconds (LES)
•
Severely errored seconds (SES)
•
Unavailable errored seconds (UAS)
•
Bipolar violation (BPV)
•
Controlled slip (CS)
•
Line code violation (LCV)
Alarms, errors, and
events
Related
Documentation
M7i PICs Description on page 3
•
•
•
M7i PIC/CFEB Compatibility on page 11
•
SONET/SDH OC3/STM1 Optical Interface Specifications
