You can install any transceiver supported by the PIC.
•
Fiber-optic small form-factor pluggable (SFP) transceivers:
•
Duplex LC/PC connector (Rx and Tx)
•
1000Base-LH (model number: SFP-1GE-LH)
•
1000Base-LX (model number: SFP-1GE-LX)
•
1000Base-SX (model number: SFP-1GE-SX)
•
Copper SFP transceiver:
•
Connector: Four-pair, Category 5 shielded twisted-pair connectivity through an RJ-45
connector
•
Pinout: MDI crossover
•
Length: 328 ft (100 m)
•
1000Base-T (model number: SFP-1-GE-T)
•
Copper interface specifications—see Gigabit Ethernet 1000BASE Optical Interface
Specifications
NOTE: Do not install SONET/SDH SFPs in the Gigabit Ethernet port. The port will not recognize
the SFP.
Cables and connectors
OK LED, one tricolor:
•
Off—PIC is offline and it is safe to remove it from the router.
•
Green—PIC is operating normally.
•
Yellow—PIC is initializing.
•
Red—PIC has an error or failure.
APP LED, one bicolor:
•
Off—Monitoring application is not running.
•
Green—Monitoring application is running under acceptable load.
Port LEDs, one per port:
•
Off—Port is not enabled.
•
Green—Port is online with no alarms or failures.
LEDs
Related
Documentation
M7i PICs Description on page 3
•
•
•
M7i PIC/CFEB Compatibility on page 11
•
Gigabit Ethernet 1000BASE Optical Interface Specifications
