Table 1: PICs Supported in the M7i Router (continued)
First Junos OS
Release
Support
Connector Model Number Ports PIC Family and Type
6.0 • 100-ohm
RJ-48
connector PE-4T1-RJ48 4 “T1 PIC (M7i Router)” on page 100
Ethernet
“Fast Ethernet PICs (M7i Router)” on page 74
6.0 • RJ-45
• Two-pair,
Category 5
unshielded
twisted-pair
• Pinout: MDI
noncrossover
PE-4FE-TX 4 • Fast Ethernet PIC
6.0 • MT-RJ female PE-8FE-FX 8 • Fast Ethernet PIC
6.0 • One very high
density
connector
interface
(VHDCI) to
RJ-21 cable
that connects
to an
RJ-45 patch
panel PE-12FE-TX-MDI
PE-12FE-TX-MDIX
12 • Fast Ethernet PIC
6.3 • Optical: LC/PC
• Copper: RJ-45
• Four-pair,
Category 5
shielded
twisted-pair
connectivity
• Pinout: MDI
crossover
PE-1GE-SFP 1 “Gigabit Ethernet PIC with SFP (M7i
Router)” on page 76
Ethernet IQ
6.0 • Optical: LC/PC
• Copper: RJ-45
• Four-pair,
Category 5
shielded
twisted-pair
connectivity
• Pinout: MDI
crossover
PE-1GE-SFP-QPP 1 “Gigabit Ethernet IQ PIC with SFP
(M7i Router)” on page 78
