Table 1: PICs Supported in the M7i Router (continued)
First Junos OS
Release
Support
Connector Model Number Ports PIC Family and Type
6.0 • Two DB-25
male
connectors
(one per port,
included with
PIC)
• V.35 requires
an EIA-530 to
V.35 cable and
connects to a
V.35 DTE
34-pin
Winchester
type male
cable (one per
port)
• X.21 requires
an EIA-530 to
X.21 cable and
connects to a
X.21 DTE DB-15
male cable
PE-2EIA530 2 “EIA-530 PIC (M7i Router)” on
page 70
SONET/SDH
8.4 • Optical: LC/PC PE-2OC3-SON-SFP 2 “SONET/SDH OC3c/STM1 PIC with
SFP (M7i Router)” on page 86
10.2 • Optical: LC/PC PE-4OC3–STM1-IQE-SFP 4 “SONET/SDH OC3/STM1 Enhanced
IQ (IQE) PIC with SFP (M7i Router)”
on page 89
8.4 • Optical: LC/PC PE-4OC3-1OC12-SON-SFP 4 “SONET/SDH OC3/STM1
(Multi-Rate) PIC with SFP (M7i
Router)” on page 91
10.2 • Optical: LC/PC PE-1OC12-STM4-IQE-SFP 1 “SONET/SDH OC12/STM4
Enhanced IQ (IQE) PIC with SFP
(M7i Router)” on page 94
8.4 • Optical: LC/PC PE-1OC12-SON-SFP 1 “SONET/SDH OC12/STM4
(Multi-Rate) PIC with SFP (M7i
Router)” on page 97
Related
Documentation
M7i PICs Description on page 3 •
• M7i PIC/CFEB Compatibility on page 11
