SFF Workstation Installation Guide
User’s Manual 61
Feature Option Description
CPU Configuration GART Error Reporting Enable only for testing purpose
IDE Configuration Enable or Disable IDE Controller
SuperIO Configuration
Configures devices connected to the Super
I/O Configuration
Floppy Configuration
Disabled
360 KB, 5 1/2”
1.2 MB, 5 1/2”
720 KB, 3 1/2”
1.44 MB, 3 1/2”
2.88 MB, 3 1/2”
Select Floppy A or Floppy B and then selects
floppy-diskette type installed in your system.
Hardware Health
Configuration
H/W health function and
H/W thermal throttling
Disabled/Enabled
1. Enable/Disable H/W health function
2. Thermal throttling allows the user to
reduce CPU duty cycle to a user defined
percentage when the temperature
reaches a user defined value
3. H/W health event
ACPI Configuration
ACPI Aware O/S
Yes/No Enable: If O/S supports ACPI
Disable: If O/S doesn’t support ACPI
Hyper Transport
Configuration CPU0: CPU1 HT Link
Speed/Width Hyper Transport link speed/width is
adjustable
USB Configuration
Legacy USB Support
Disabled/Enabled/Auto
USB Mass Storage Device
Configuration
1. Enables support for legacy USB. Auto
option disables legacy support if no USB
devices are connected
2. Configure the USB mass storage class
devices
Onboard Device
Configuration
SATA and 1394 controller
Enable or disable onboard SATA and 1394
controller
