IBM Dual AMD OpteronTM SFF Barebone ZMAXdp User Manual
Page 18
IWILL ZMAXdp
18 User’s Manual
Turn over the drive holder
Release the screws from the CDROM/ HDD rack with a screw driver.
Release the screws from the rack
Release the two screws holding the rack to the
casing. Set one screws aside..
Remove this screw
Remove another screw holding the rack to the
casing and set it aside.
Pull drive holder up
Draw the drive holder a little bit. Pull up the holder,
fix the rack on the casing and make it steady.
