IBM Dual AMD OpteronTM SFF Barebone ZMAXdp User Manual
Page 20
IWILL ZMAXdp
20 User’s Manual
Remove the pre-installed heatsink assembly
To install the CPU, it is necessary to remove the pre-installed heatsink module. Please remove six
screws from heatsink. Gently handle the heatsink module. Avoid hitting, falling or throwing down
the heatsink.
Remove the screws (marked in circles)
