IBM Dual AMD OpteronTM SFF Barebone ZMAXdp User Manual
Page 25
SFF Workstation Installation Guide
User’s Manual 25
Installing the heatsink and tighten the screws
Place the screws and tighten down the heatsink. Do not over-tighten the screws. Ensure that the
retention heatsink bases are flat with the motherboard.
Secure the each screw one by one and follow the number sequence shown as the illustrator.
Note: The bottom of the heatsink is parallel with the motherboard. This is the only
proper way to install the heatsink.
