IBM Dual AMD OpteronTM SFF Barebone ZMAXdp User Manual
Page 43
SFF Workstation Installation Guide
User’s Manual 43
Ethernet Ports
The two LAN Ports are RJ-45 connectors for standard Cat 5 LAN cabling. The connectors attach
to the onboard CK8 MAC and MARVELL GbE PHY respectively.
USB Ports
There are four high-speed USB 2.0 ports, USB 0 and USB 1, for connecting either USB 1.1 or 2.0
devices to the system. It does not matter if the system is on when you connect or disconnect USB
devices. See the graphic below.
Audio Jacks
Line In: provides audio input connector for an external audio source.
Speaker: offers output to two stereo speakers.
Microphone: this jack is for plugging in a computer microphone.
