Intel® Server Board SDS2 Connections
Revision 1.2
Order Number: A85874-002
83
Pin Signal Name
1 Fused 5 V
2 USB_PORT1_D-
3 USB_PORT1_D+
4 GND
5 Fused 5 V
6 USB_PORT2_D-
7 USB_PORT2_D+
8 GND
9 Fused 5 V
10 USB_PORT3_D-
11 USB_PORT3_D+
12 GND
A 10-pin header (2X5) located at CN18 on the Server Board provides an option to cable out the
USB to the front panel. The pin-out of the header is detailed in the following table that is
representative of the Foxconn HL07051-P9 Housing located at CN18.
Pin 6 +5Volts Pin 7
USB_PORT4_D- Pin 8
USB_PORT4_D
+ Pin 9 GND Pin 10 N/C
Pin 1 N/C Pin 2 N/C Pin 3 N/C Pin 4 N/C Pin 5 KEY
Table 68. 10-pin USB Connection Header (2 x 5) Pin-out
Pin Signal name
1 N/C
2 N/C
3 N/C
4 N/C
5 KEY
6 Fused 5 V
7 USB_PORT4_D-
8 USB_PORT4_D+
9 GND
10 N/C
8.6.6 Floppy Connector
The following table details the pin-out of the 34-pin floppy connector.
