Page 29

Intel® Server Board SDS2

I/O Subsystem

Revision 1.2

Order Number: A85874-002

Table 9. Video Modes

SDS2 2D Mode Video Support

2D Mode

Refresh Rate (Hz)

8 bpp

16 bpp

24 bpp

32 bpp

640x480

60, 72, 75, 90, 100

Supported

800x600

60, 70, 75, 90, 100

Supported

1024x768

60, 72, 75, 90, 100

Supported

1280x1024

43, 60

Supported

–

1280x1024

70, 72

Supported

–

Supported

–

1600x1200

60, 66, 76, 85

Supported

–

3D Mode

Refresh Rate (Hz)

SDS2 3D Mode Video Support with Z Buffer Enabled

640x480

60, 72, 75, 90, 100

Supported

800x600

60, 70, 75, 90, 100

Supported

–

1024x768

60, 72, 75, 90, 100

Supported

–

1280x1024

43, 60, 70, 72

–

1600x1200

60, 66, 76, 85

–

3D Mode

Refresh Rate (Hz)

SDS2 3D Mode Video Support with Z Buffer Disabled

640x480

60, 72, 75, 90, 100

Supported

800x600

60, 70, 75, 90, 100

Supported

1024x768

60, 72, 75, 90, 100

Supported

–

1280x1024

43, 60, 70, 72

Supported

–

1600x1200

60, 66, 76, 85

Supported

–

4.4 Network Interface Controller (NIC)

The SDS2 Server Board supports two 10Base-T / 100Base-TX network subsystem using the
Intel 82550-PM NIC. The 82550 components are highly integrated PCI LAN controllers in a thin
BGA 15 mm2 package. The controller’s baseline functionality is equivalent to that of the Intel
82559 with the addition of Alert on LAN* functionality.

The SDS2 Server Board supports independent disabling of either of the two NIC controllers
under BIOS setup menu.

The 82550 supports the following features:

•

32-bit PCI/Card Bus master interface

•

Integrated IEEE 802.3 10Base-T and 100Base-TX compatible PHY

•

IEEE 820.3u auto-negotiation support

•

Chained memory structure similar to the 82559, 82558, 82557 and 82596

•

Full duplex support at both 10 and 100 Mbps operation

•

Low power +3.3 V device
