Intel SERVER BOARD SDS2 User Manual
Page 38
I/O Subsystem
Intel® Server Board SDS2
Revision 1.2
Order Number: A85874-002
24
PCI IRQ 6
PCI IRQ 5
PCI IRQ 13
PCI IRQ 11
PCI IRQ 12
NIC 1
NIC 2
VIDEO
INTA
INTB
INTC
INTD
SCSI
PORT A
PORT B
Slot 2
Slot 1
Slot 4
Slot 3
Slot 6
Slot 5
PCI IRQ 7
PCI IRQ 8
PCI IRQ 9
PCI IRQ 10
PCI IRQ 2
PCI IRQ 3
PCI IRQ 4
PCI IRQ 0
PCI IRQ 1
ZCR Present
Figure 5. SDS2 PCI Interrupt Mapping Diagram
