Intel SERVER BOARD SDS2 User Manual
Page 56
BIOS
Intel® Server Board SDS2
Revision 1.2
Order Number: A85874-002
42
Sensor
Name
Sensor
#
Sensor Type
Event/
Reading
Type
Event
Offset
Triggers
Fan Boost
Front Panel
Temp
3Ch
OEM - C7h
Threshold -
01h
-
Fan Boost
PDB Temp
3Dh
OEM - C7h
Threshold -
01h
-
Fan Boost
Proc 1 Core
Temp
3Eh
OEM - C7h
Threshold -
01h
-
Fan Boost
Proc 2 Core
Temp
3Fh
OEM - C7h
Threshold -
01h
-
Tach Fan 1
48h
Fan - 04h
Threshold -
01h
-
Tach Fan 2
49h
Fan - 04h
Threshold -
01h
-
Tach Fan 3
4Ah
Fan - 04h
Threshold -
01h
-
Tach Fan 4
4Bh
Fan - 04h
Threshold -
01h
-
Tach Fan 5
4Ch
Fan - 04h
Threshold -
01h
-
Tach Fan 6
4Dh
Fan - 04h
Threshold -
01h
-
Digital Fan 1
50h
Fan - 04h
Digital
Discrete - 06h
Performance Lags
Digital Fan 2
51h
Fan - 04h
Digital
Discrete - 06h
Performance Lags
Digital Fan 3
52h
Fan - 04h
Digital
Discrete - 06h
Performance Lags
Digital Fan 4
53h
Fan - 04h
Digital
Discrete - 06h
Performance Lags
Digital Fan 5
54h
Fan - 04h
Digital
Discrete - 06h
Performance Lags
Digital Fan 6
55h
Fan - 04h
Digital
Discrete - 06h
Performance Lags
PDB Fan 1
58h
Fan - 04h
Threshold -
01h
-
PDB Fan 2
59h
Fan - 04h
Threshold -
01h
-
Power
Supply 1
5Ah
Power Supply -
08h
Sensor
Specific - 6Fh
Presence,
Failure,
Predictive Fail,
A/C Lost
