Figure 96. timer 2 control register, Figure 9-6) – Intel 80C188XL User Manual
Page 238

9-9
TIMER/COUNTER UNIT
Figure 9-6. Timer 2 Control Register
Register Name:
Timer 2 Control Register
Register Mnemonic:
T2CON
Register Function:
Defines Timer 2 operation.
Bit
Mnemonic
Bit Name
Reset
State
Function
EN
Enable
0
Set to enable the timer. This bit can be written
only when the INH bit is set.
INH
Inhibit
X
Set to enable writes to the EN bit. Clear to
ignore writes to the EN bit. The INH bit is not
stored; it always reads as zero.
INT
Interrupt
X
Set to generate an interrupt request when the
Count register equals a Maximum Count
register. Clear to disable interrupt requests.
MC
Maximum
Count
X
This bit is set when the counter reaches a
maximum count.
The MC bit must be cleared
by writing to the Timer Control register. This
is not done automatically. If MC is clear, the
counter has not reached a maximum count.
CONT
Continuous
Mode
X
Set to cause the timer to run continuously.
Clear to disable the counter (clear the EN bit)
after each counting sequence.
NOTE:
Reserved register bits are shown with gray shading. Reserved bits must be written
to a logic zero to ensure compatibility with future Intel products.
A1298-0A
15
0
C
O
N
T
M
C
I
N
T
I
N
H
E
N
