Middleby Marshall RED LOBSTER PS200-R68 - Manual (Page 65)

59
SECTION 6
PARTS LIST
6-1
6-2
6-3
6-4
6-5
6-6
6-7
6-8
6-9 Oven Panels, Window and Legs Exploded Drawing
Air Finger Exploded Drawing
Control Panel Exploded Drawing
Blower and Shroud Exploded Drawing
Conveyor Exploded Drawing
Gas Burner and Piping Assembly Exploded Drawing
Machinery Compartment Exploded Drawing
Electric Oven Electrical Panel Drawing
Junction Box and Export Transformer Exploded Drawing
NOTE: Throughout Section 6 parts lists the following abbre-
viations are used:
A/R = Quantity as required
N/A = Does not apply
SECTION 6
PARTS LIST
FIGURE NO. DESCRIPTION PAGE NO.
60
62
64
66
68
70
72
74
76
