42
SECTION 4
MAINTENANCE
4. Cleaning fingers.
WARNING: Clean one finger at a time. Only one finger at a time should be disassembled because
the parts of the fingers are not interchangeable.
a. Finger assemblies are made up of an outer plate, inner plate and finger manifold as shown in Figure 4-16.
b. When cleaning finger assemblies check one assembly at a time to see if the inner plate needs scrubbing.
Disassemble only one finger at a time and after cleaning the inner plate and the manifold, reassemble the
finger before disassembling the next finger.
Large Holes &
Perforated
Outer Plate with
3 Rows of Holes
5-
5/3
2"
R
ea
r
Op
en
ing
FB M3RN FB M3RN
M6 M6 M6 M6
Product Direction (Either Direction)
Upper Fingers
Lower Fingers
RED LOBSTER FINGER CONFIGURATION IN OVEN
No Large Holes,
Perforated Only
Raised Front
(Stamped "UPPER")
Outer Plate
with 6 Rows
of Holes
M3RN
Finger
M6
Finger
Full
Blank
UP
PE
R
UP
PE
R
Stamped "UPPER"
4-
1/3
2"
R
ea
r
Op
en
ing
Baffle
Manifold
Inner
Plate
Manifold
Inner
Plate
Figure 4-16.
