Building a Custom Edge 3000 Chassis 4-7
Building the Custom Chassis
UltraNet ConfigManager automatically assigns a name and
number to each icon that represents the UltraNet Edge 3000, for
example Node10 and Node20.
The node icons and their corresponding names are also displayed
under the NetMap1 heading in the TreeView Area on the left.
16. Continue configuring the Network Map by using the appropriate
chapter for the type of network you are configuring, beginning
with the “Setting the Initial Configuration” section:
— If you are configuring an implementation using E_port
extension over an Ethernet WAN, use Chapter 5, Configuring
an E_Port Extension over an Ethernet WAN as an example.
— If you are configuring an implementation using F_port over
an Ethernet WAN, use Chapter 6, Configuring an F_Port
Extension over an Ethernet WAN as an example.
— If you are configuring an implementation using E_port
extension over an ATM WAN, use Chapter 7, Configuring an
E_Port Extension over an ATM WAN as an example.
— If you are configuring an implementation using FICON
extension over an Ethernet WAN, use Chapter 8, Configuring
FICON Extension as an example.
— If you are configuring a FC/SCSI Tape Pipelining
implementation, use Chapter 9, Configuring Tape Device
Extension as an example.
