CC-Link Parameters
2
CC-
L
in
k CO
M
M
UNICAT
ION
2.2 CC-Link Parameters
2.2.1 CC-Link Extended Setting (Pr. 544)
Remote register function can be extended.
*1 The program used for conventional series inverter (FR-A5NC) can be used.
*2 When using double, quadruple and octuple settings of the CC-Link Ver.2, station data of
the master station must be set to double, quadruple and octuple also.
(If the master station is CC-Link Ver.1 compatible station, the above setting can not be
made.)
Parameter
Number
Name
Initial
Value Setting
Range
Description CC-Link
Ver.
544
CC-Link extended
setting
0
0
1
Occupies one station
(FR-A5NC compatible)
*1
1 Occupies one station
12 *2
2
Occupies one station double
14 *2
Occupies one station
quadrople
18 *2 Occupies one station octuple
100 1
Occupies one station
(PLC function)
112 *2
2
Occupies one station double
(PLC function)
114 *2
Occupies one station
quadrople (PLC function)
118 *2
Occupies one station octuple
(PLC function)
REMARKS
The setting change is reflected after an inverter reset.
